Effective central
software & easy to connect and
use with mobile phones for the users
Bellia series bring artisan way of quality together with exclusive technology.
Material | Stainless Steel / Powder Coated Metal |
---|---|
Dimensions (DXLXH mm) | 355 x 380 x 1100 |
Weight | 22 kg |
Operating Temperature | -30°C + 60°C |
IP Rating | Pedestal IP66 |
Sockets IP67 | |
Impact Rating | IK 10 |
Compliances | CE Certified |
EN 61439-7 | |
EN 62208 | |
Low/High Temperature EN 60068-2 | |
IP Rating EN 60529 | |
Impact Rating EN 62262 | |
Solar Radiation EN 60068-2-5 | |
Salt Fog/Mist/Corosion EN 60068-2-52 | |
Number of outlets | Power: 1 to 4 |
Water: 1 to 4 | |
Sockets | 16A Single Phase to 250A Three Phase |
Voltage | 115v to 400V / 50-60 Hz |
Overload & Fault Current Protection | Seperate for each outlet |
Taps | 1/2” valves, quick coupling |
Metering | Electricity and water metering with remote |
monitoring and prepaid system |
